Maintex Stepper Motor 5v Dc 12V 5.625 Degree 24BYJ48-032 Stepping Motor PM with Gearbox Maintex 24byj Stepper Motor

Welcome to Getitfy , click camera icon to search using image to source or paste 1688/Taobao link in search bar

Catalog Power Transmission Motors Stepper Motors

Link to original

Code: alb-60442749967

Sold: 0 PCs In stock: 99999
Step Angle(degrees): 5.625 Degree step angle(degrees):
Holding Torque: ≥80 mN.m holding torque:
Price per 1 piece :
Quantity: pieces, in the amount of
Total:
Loaded translation of the description of the goods Add to cart Remove from cart PCs Loading product reviews This product is not available Added to the cart! Remove from cart The goods are not added, please try again later Product removed from your cart! Add to cart The goods are not removed, try again! Quick order Remove from cart Add to cart Remove item from favorites Add to favorites

Name: Shenzhen Maintex Intelligent Control Co., Ltd.
Rating:

Delivery 4.9	Item 5	Service 4.9
Add vendor to favourites

Product details
Step Angle(degrees):	5.625 Degree;
Holding Torque:	≥80 mN.m;
Warranty:	3months-1year;
Place of Origin:	Guangdong, China;
Brand Name:	MAINTEX;
Model Number:	24BYJ48-032;
Phase:	4;
Type:	Permanent Magnet;
Current / Phase:	0.1-0.4A;
Title:	Dc 12V 5.625 Degree 24BYJ stepping motor PM with gearbox;
Voltage:	12v; can be Customzied;
Resistance/Phase:	21Ω±10%/phase;
No load pull out frequency:	≥1000HZ;
No load pull in frequency:	≥500HZ;
Reduction ratio:	1/64;
Pull in toque:	≥80 mN.m;
Detent toque:	≥80mN.m;
Noise:	≤40dB(A);
Diameter:	24mm;
